Code: BTCB/BLCB
Description: 3-Way Clamp ball valve with Mounting Pad Rev. B
Application:Water, Oil, Gas
Features:
* Material: Investment Cast Body&Cap CF8M/CF8
* Connection: Threaded
* Pressure: 200PSI
* Size: 1/4”-2”
* Standard:
Design: API608
Inspection: API598, EN12266
100% Tested at 100 PSI (7 Bars) Open & Close Position
* Options:
L type or T type
Wide Range Of Seat And Seal Materials Available
Locking lever
Design Advantage:
*Reduce bore
* Blow-out Proof Stem SS316
* 3-piece Swing-out Design
* Adjustable Stem Packing
* Anti static device- standard applied between stem and body, stem and ball
* Extra high cycle life
*Anti-static structure
*ISO 5211 standard actuator mounting pad
