3PC Butt Weld Ball Valve

Code: Q3B8(7)

Description: 3PC Butt Weld Ball Valve

Application：Water, Oil, Gas

Features:

* Material: Investment Cast Body & Cap CF8M/CF8

* Connection: Butt Weld

* Pressure: 1000PSI for 1/4” to 2” and 800PSI for 2-1/2” to 4”.

* Size: 1/4”-4”

* Standard:

  Design: API608

  Inspection: API598, EN12266

  Butt Weld: ASME B1 6.25

  100% Tested at 100 PSI (7 Bars) Open & Close Position

* Options:

  Wide Range Of Seat And Seal Materials Available

  Locking lever

* Approvals: ATEX

Design Advantage:

* Blow-out Proof Stem SS316

* Adjustable Stem Packing

* Extra high cycle life
